EX-1545

Download data sheet

Product description

EX-1545 is a 2-part highly modified, tough cyanate ester resin formulated to have extremely low viscosity at room temperature. The low viscosity allows RTM processing with minimal heat to the resin, which extends resin pot life and mold filling time for difficult and/or large RTM’d structures. EX 1545 displays both excellent mechanical and thermal properties in addition to low moisture absorption. Finally, the material is unique in that it develops full mechanical properties from its initial 177°C (350°F) cure.

Product benefits/features

  • Toughened resin system with low viscosity of 140 cPs at 43°C (110°F)
  • Long pot life for complex parts

Market segments

  • Space & Satellite
  • Radome

Details

Product category RTM resins
Processing Press forming
Resin type Cyanate Ester
Tg (Dry, onset) 177 °C / 350 °F
Cure temperature (Optimal) 177 °C / 350 °F
Cure temperature (Lowest) 177 °C / 350 °F
Cure temperature (Highest) 177 °C / 350 °F
Out life 24 hours
